Bradbury H8935MG1 3.5 Tonne Mobile or Fixed Scissor Lift

Bradbury H8935MG1 Mobile or Fixed Scissor Lift (3.5 tonne)

Finance options available (Subject to credit)


The Bradbury H8935MG/1 is our newest addition! An electro-hydraulic mobile, short-rise scissor lift with a large 3.5 tonne lifting capacity. Double hydraulic system with two cylinders under each platform, meaning that no compressed air for the safety ratchets is required. Mobile kit and rubber blocks included as standard!



Brand: Bradbury


CALL FOR PRICE

Tech Spec

Lifting capacity 3.5 tonne
Lifting/lowering time 16 seconds
Platform length 1400-1975mm
Lift minimum height 115mm
Working height 1000mm + rubber pads
Distance between platforms 1000mm
Platform width 630mm
Motor size – Single phase 1 phase – 1.5kW
Pump unit 2.2KW
Power Requirements 1 phase – 20a Isolator Required, 3 phase – 16a Isolator Required
Stroke length 895mm
Operation Electro-Hydraulic

Features

  • Double hydraulic system with two cylinders under each scissor system, meaning no compressed air and no safety ratchet needed!
  • Leverage of full 3.5 tonne capacity from lowest position.
  • Mechanic synchronization through cross-bars.
  • Sturdy scissor construction for high directional stability.
  • Base-frames, platforms and ramps galvanised as standard.
  • Mobile kit and rubber blocks included as standard.
